CNQPacketQueue Class Reference

Implementation of platform (and stack) independent FIFO packet queue for objects of type CNQMessage. More...

#include <NQPacketQueue.h>

Collaboration diagram for CNQPacketQueue:

List of all members.

Public Member Functions

CNQPacketQueue ()

virtual ~CNQPacketQueue ()

bool setQueueMaxsize (INT32 maxsize, UINT32 &lasterr)

Adjust the Queue depth.

UINT32 getLastError ()

Returns last error code happened.

bool pop_front (CNQMessage **obj, UINT32 &lasterr)

Gets the first message (FIFO) out of the queue.

bool push_back (const CNQMessage *obj, UINT32 &lasterr)

Appends a CNQMessage object to the end of the (FIFO) queue.

bool remove_elem (UINT16 requestid, UINT32 &lasterr)

bool find_elem (UINT16 requestid, CNQMessage **obj, UINT32 &lasterr)

bool find_and_remove_elem (UINT16 requestid, CNQMessage **obj, UINT32 &lasterr)

int size (UINT32 &lasterr)

bool find_elem_ack_and_signal (const CNQMessage &aAckPacket, UINT32 &lasterr)

bool find_and_remove_passed_elem (CNQMessage *obj, UINT32 &lasterr)

bool setQueueMaxsize (INT32 maxsize)

bool pop_front (CNQMessage **obj)

bool push_back (const CNQMessage *obj)

bool remove_elem (UINT16 requestid)

bool find_elem (UINT16 requestid, CNQMessage **obj)

bool find_and_remove_elem (UINT16 requestid, CNQMessage **obj)

int size ()

Returns the current amount of elements stored in the queue.

bool find_elem_ack_and_signal (const CNQMessage &aAckPacket)

bool find_and_remove_passed_elem (CNQMessage *obj)

Private Attributes

INT32 m_iQueueFirstElement

INT32 m_iQueueLastElement

INT32 m_iQueueNumElements

VOIDP * m_pQueueValue

INT32 * m_iQueueNextElement

INT32 m_iQueueMaxSize

UINT32 m_iLastError

Friends

class CNQMessage

Detailed Description

Implementation of platform (and stack) independent FIFO packet queue for objects of type CNQMessage.

Using C++ STL this could be done much more easily, but implementation on Nios2 platform did not work (reason not fully known, stack issues suspected). This CNQPacketQueue was created as a slightly inferior, but working solution.

Implementation details:

double array linked list
access protected by binary semaphore or mutex object
no data is copied, only pointer reference
enhanced error handling

Definition at line 25 of file NQPacketQueue.h.

Constructor & Destructor Documentation

CNQPacketQueue::CNQPacketQueue ( )

Definition at line 14 of file NQPacketQueue.cpp.

CNQPacketQueue::~CNQPacketQueue ( ) [virtual]

Definition at line 39 of file NQPacketQueue.cpp.

Member Function Documentation

bool CNQPacketQueue::setQueueMaxsize	(	INT32	maxsize,
		UINT32 &	lasterr
	)

Adjust the Queue depth.

This method adjusts the queue depth by reinitializing the queue pool. Any data accumulated in the queue might be lost after readjustment.

Parameters:

	maxsize	new 'queue depth'
	lasterr	unique error code

Return values:

	true	successfully readjusted to 'maxsize' depth
	false	failure, something happened (see lasterr) if lasterr ERR_PQ_LOCK, mutex locking failed

See also:: Network Queue Error Codes

Definition at line 124 of file NQPacketQueue.cpp.

Referenced by CNetworkQueue::CNetworkQueue(), and setQueueMaxsize().

Here is the call graph for this function:

Here is the caller graph for this function:

UINT32 CNQPacketQueue::getLastError ( )

Returns last error code happened.

for detailed list of possible error codes, see Declarations.h

See also:: Network Queue Error Codes

Definition at line 768 of file NQPacketQueue.cpp.

bool CNQPacketQueue::pop_front	(	CNQMessage **	obj,
		UINT32 &	lasterr
	)

Gets the first message (FIFO) out of the queue.

Parameters:

	obj	place to store extracted element (empty variable of type CNQMessage)
	lasterr	unique error code

Return values:

	true	successful, first element extracted and put to **obj
	false	failure, something happened (see lasterr)

Errorcodes:

ERR_PQ_LOCK mutex locking failed
- ERR_PQ_BADPARAM obj is NULL
- ERR_PQ_NONE queue is empty, so no object was returned

Note:: This function contains assert() which gives more failure reasons during development/debugging.

See also:: Network Queue Error Codes

Definition at line 177 of file NQPacketQueue.cpp.

Referenced by CNetworkQueue::close(), pop_front(), CNetworkQueue::recvMsg(), and CNetworkQueue::SendProcessTask().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::push_back	(	const CNQMessage *	obj,
		UINT32 &	lasterr
	)

Appends a CNQMessage object to the end of the (FIFO) queue.

Parameters:

	obj	object reference to store
	lasterr	unique error code

Return values:

	true	successful, element reference to obj appended
	false	failure, something happened (see lasterr)

Errorcodes:

ERR_PQ_LOCK mutex locking failed
ERR_PQ_BADPARAM obj is NULL
ERR_PQ_FULL queue is full

Note:: This function contains assert() which gives more failure reasons during development/debugging.

See also:: Network Queue Error Codes

Definition at line 239 of file NQPacketQueue.cpp.

Referenced by push_back(), CNetworkQueue::ReceiveProcessTask(), CNetworkQueue::sendMsgTo(), and CNetworkQueue::sendMsgToInternal().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::remove_elem	(	UINT16	requestid,
		UINT32 &	lasterr
	)

This method traverses the queue, looks for a CNQMessage element that contains the 'requestid' and removes it.

Parameters:

	requestid	CNQMessage object's request id (this object will be removed from the queue if found)
	lasterr	unique error code

Return values:

	true	successful, element reference was removed
	false	failure, something happened (see lasterr)

Errorcodes:

ERR_PQ_LOCK mutex locking failed
ERR_PQ_NOTFOUND CNQMessage object with 'requestid' was not found

Note:: This function contains assert() which gives more failure reasons during development/debugging.

See also:: Network Queue Error Codes

Definition at line 327 of file NQPacketQueue.cpp.

Referenced by remove_elem().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::find_elem	(	UINT16	requestid,
		CNQMessage **	obj,
		UINT32 &	lasterr
	)

This method traverses the queue, looks for a CNQMessage element that contains the 'requestid' and returns it without removeing it.

Parameters:

	requestid	CNQMessage object's request id (this object will be returned if found)
	obj	place to store element, if found (empty variable of type CNQMessage *)
	lasterr	unique error code

Return values:

	true	successful, element is returned
	false	failure, something happened, element is NOT returned (see lasterr)

Errorcodes:

ERR_PQ_LOCK - mutex locking failed
ERR_PQ_NOTFOUND - CNQMessage object with 'requestid' was not found
- ERR_PQ_BADPARAM - obj is NULL

See also:: Network Queue Error Codes

Definition at line 428 of file NQPacketQueue.cpp.

Referenced by find_elem().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::find_and_remove_elem	(	UINT16	requestid,
		CNQMessage **	obj,
		UINT32 &	lasterr
	)

This method traverses the queue, looks for a CNQMessage element that contains the 'requestid' and returns it. The object reference is removed from the queue.

Parameters:

	requestid	CNQMessage object's request id (this object will be returned if found)
	obj	place to store element, if found (empty variable of type CNQMessage *)
	lasterr	unique error code

Return values:

	true	successful, element is returned and removed from queue
	false	failure, something happened, element is NOT returned (see lasterr)

Errorcodes:

ERR_PQ_LOCK - mutex locking failed
ERR_PQ_NOTFOUND - CNQMessage object with 'requestid' was not found
ERR_PQ_BADPARAM - obj is NULL

note\ This function contains assert() which gives more failure reasons during development/debugging.

See also:: Network Queue Error Codes

Definition at line 666 of file NQPacketQueue.cpp.

Referenced by find_and_remove_elem(), and CNetworkQueue::sendRecvMsg().

Here is the call graph for this function:

Here is the caller graph for this function:

int CNQPacketQueue::size ( UINT32 & lasterr )

Referenced by CNetworkQueue::close().

Here is the caller graph for this function:

bool CNQPacketQueue::find_elem_ack_and_signal	(	const CNQMessage &	ack_packet,
		UINT32 &	lasterr
	)

This method traverses the queue, looks for a CNQMessage element that matches the passed 'ack packet' and signals the attached semaphore in case a match is found.

This method is used in order to signal 'waiting to be ACKed' packets inside ReceiveProcessTask on successful reception of an ACK packet.

Parameters:

	ack_packet	CNQMessage object's ack_packet
	lasterr	unique error code

Return values:

	true	successful, element is returned
	false	failure, something happened, element is NOT returned (see lasterr)

Errorcodes:

ERR_PQ_LOCK - mutex locking failed
ERR_PQ_NOTFOUND - CNQMessage object looking for ack_packet was not found
ERR_PQ_BADPARAM - ack_packet is no 'ack packet'

Note:: In case of debug version a special assert is thrown in case the semaphore could not be signalled.

See also:: Network Queue Error Codes

Definition at line 495 of file NQPacketQueue.cpp.

Referenced by find_elem_ack_and_signal(), and CNetworkQueue::ReceiveProcessTask().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::find_and_remove_passed_elem	(	CNQMessage *	obj,
		UINT32 &	lasterr
	)

This method traverses the queue, looks for a CNQMessage element that matches the passed CNQMessage and, if found, removes the object reference from the queue.

Parameters:

	obj	a valid CNQMessage to look for inside the queue
	lasterr	unique error code

Return values:

	true	successful, element is returned and removed from queue
	false	failure, something happened, element is NOT returned (see lasterr)

Errorcodes:

ERR_PQ_LOCK - mutex locking failed
ERR_PQ_NOTFOUND - CNQMessage object with 'requestid' was not found
ERR_PQ_BADPARAM - obj is NULL

Note:: This function contains assert() which gives more failure reasons during development/debugging.

See also:: Network Queue Error Codes

Definition at line 564 of file NQPacketQueue.cpp.

Referenced by find_and_remove_passed_elem(), and CNetworkQueue::sendMsgTo().

Here is the call graph for this function:

Here is the caller graph for this function:

bool CNQPacketQueue::setQueueMaxsize ( INT32 maxsize )

Definition at line 49 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::pop_front ( CNQMessage ** obj )

Definition at line 56 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::push_back ( const CNQMessage * obj )

Definition at line 63 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::remove_elem ( UINT16 requestid )

Definition at line 70 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::find_elem	(	UINT16	requestid,
		CNQMessage **	obj
	)

Definition at line 77 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::find_and_remove_elem	(	UINT16	requestid,
		CNQMessage **	obj
	)

Definition at line 84 of file NQPacketQueue.cpp.

Here is the call graph for this function:

int CNQPacketQueue::size ( )

Returns the current amount of elements stored in the queue.

Return values:

	>0	number of elements in queue
	0	failure or queue is empty (see lasterr)

Definition at line 756 of file NQPacketQueue.cpp.

bool CNQPacketQueue::find_elem_ack_and_signal ( const CNQMessage & aAckPacket )

Definition at line 91 of file NQPacketQueue.cpp.

Here is the call graph for this function:

bool CNQPacketQueue::find_and_remove_passed_elem ( CNQMessage * obj )

Definition at line 98 of file NQPacketQueue.cpp.

Here is the call graph for this function:

Friends And Related Function Documentation

friend class CNQMessage [friend]

Definition at line 27 of file NQPacketQueue.h.

Member Data Documentation

INT32 CNQPacketQueue::m_iQueueFirstElement [private]

Definition at line 58 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), find_elem(), find_elem_ack_and_signal(), pop_front(), push_back(), remove_elem(), and setQueueMaxsize().

INT32 CNQPacketQueue::m_iQueueLastElement [private]

Definition at line 59 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), pop_front(), push_back(), remove_elem(), and setQueueMaxsize().

INT32 CNQPacketQueue::m_iQueueNumElements [private]

Definition at line 60 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), find_elem(), find_elem_ack_and_signal(), pop_front(), push_back(), remove_elem(), setQueueMaxsize(), and size().

VOIDP* CNQPacketQueue::m_pQueueValue [private]

Definition at line 62 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), find_elem(), find_elem_ack_and_signal(), pop_front(), push_back(), remove_elem(), setQueueMaxsize(), and ~CNQPacketQueue().

INT32* CNQPacketQueue::m_iQueueNextElement [private]

Definition at line 63 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), find_elem(), find_elem_ack_and_signal(), pop_front(), push_back(), remove_elem(), setQueueMaxsize(), and ~CNQPacketQueue().

INT32 CNQPacketQueue::m_iQueueMaxSize [private]

Definition at line 65 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), push_back(), and setQueueMaxsize().

UINT32 CNQPacketQueue::m_iLastError [private]

Definition at line 67 of file NQPacketQueue.h.

Referenced by CNQPacketQueue(), find_and_remove_elem(), find_and_remove_passed_elem(), find_elem(), find_elem_ack_and_signal(), getLastError(), pop_front(), push_back(), remove_elem(), and setQueueMaxsize().

The documentation for this class was generated from the following files:


Public Member Functions
	CNQPacketQueue ()
virtual	~CNQPacketQueue ()
bool	setQueueMaxsize (INT32 maxsize, UINT32 &lasterr)
	Adjust the Queue depth.
UINT32	getLastError ()
	Returns last error code happened.
bool	pop_front (CNQMessage **obj, UINT32 &lasterr)
	Gets the first message (FIFO) out of the queue.
bool	push_back (const CNQMessage *obj, UINT32 &lasterr)
	Appends a CNQMessage object to the end of the (FIFO) queue.
bool	remove_elem (UINT16 requestid, UINT32 &lasterr)
bool	find_elem (UINT16 requestid, CNQMessage **obj, UINT32 &lasterr)
bool	find_and_remove_elem (UINT16 requestid, CNQMessage **obj, UINT32 &lasterr)
int	size (UINT32 &lasterr)
bool	find_elem_ack_and_signal (const CNQMessage &aAckPacket, UINT32 &lasterr)
bool	find_and_remove_passed_elem (CNQMessage *obj, UINT32 &lasterr)
bool	setQueueMaxsize (INT32 maxsize)
bool	pop_front (CNQMessage **obj)
bool	push_back (const CNQMessage *obj)
bool	remove_elem (UINT16 requestid)
bool	find_elem (UINT16 requestid, CNQMessage **obj)
bool	find_and_remove_elem (UINT16 requestid, CNQMessage **obj)
int	size ()
	Returns the current amount of elements stored in the queue.
bool	find_elem_ack_and_signal (const CNQMessage &aAckPacket)
bool	find_and_remove_passed_elem (CNQMessage *obj)
Private Attributes
INT32	m_iQueueFirstElement
INT32	m_iQueueLastElement
INT32	m_iQueueNumElements
VOIDP *	m_pQueueValue
INT32 *	m_iQueueNextElement
INT32	m_iQueueMaxSize
UINT32	m_iLastError
Friends
class	CNQMessage
